APOLLO
APOLLO 2.0 FLUID NOZZLE ONLY 7503-20
APOLLO 2.0 FLUID NOZZLE ONLY 7503-20
Regular price
$69.00
Regular price
Sale price
$69.00
Unit price
per
Couldn't load pickup availability
2.0 FLUID NOZZLE ONLY
7700/7500 Needles / Nozzles & Air Caps
Select from these Genuine Apollo needle, nozzle and color-coded air cap options to match your material viscosity, turbine model and specific application needs. Parts may be ordered separately or in sets (see below charts).
| FLUID NEEDLES / NOZZLES (7700/7500 Series) | Air Caps Not Included In Sets |
| Size | Material Recommendations | Needle Part # | Nozzle Part # | Needle/Nozzle Set Part # | Air Caps | Air Cap Part # |
|---|---|---|---|---|---|---|
| 0.8mm | Inks, Dyes, Stains, extremely thin viscosity fluids, Water based finishes | A7520-08 | A7503-08 | A7503-SET-08 | A (Green) | A7502-08 |
| 1.0mm | All purpose, thin lacquers, thins enamels, Water based finishes | A7520-10 | A7503-10 | A7503-SET-10 | B or B-HS (Gold) | A7502-10 or A7502-10-HS |
| 1.3mm | Similar to the 1.00mm but slightly higher viscosity | A7520-1315 | A7503-13 | A7503-SET-13 | B or B-HS (Gold) | A7502-10 or A7502-10-HS |
| 1.5mm | Catalyzed lacquers, Conversin Varnish, Primers, Varnish, High Viscosity Industrial Coatings, Urethanes, Enamels | A7520-1315 | A7503-15 | A7503-SET-15 | B or B-HS (Gold) | A7502-10 or A7502-10-HS |
| 1.8mm | Similar to the 1.5mm but slightly higher viscosity | A7503-18 | A7503-18 | A7503-SET-18 | C or C-HS (Blue) | A7502-18 or A7502-18-HS |
| 2.0mm | Thinned Latex paint, Multi-spec, Heavy Primers, Butyrate, nitrate dope, High Viscosity Industrial Coatings | A7503-20 | A7503-20 | A7503-SET-20 | C or C-HS (Blue) | A7502-18 or A7502-18-HS |
Select from these Genuine Apollo Needle, Nozzle and Air Cap options to match your material viscosity, turbine model and specific application needs.
